Wire Cutter 45mm, Li-Ion, Standard, 230V

5,637.42$

Export model, 230 V

Standard residential and commercial power in Quebec is 115 V, 60 Hz. This 230 V model will not run on an ordinary outlet without a transformer.

Add the desired quantity to the selected products.

  • Designed specifically to cut ACSR, guy strand and ground rods.
  • Shock-Load Damping System design to minimize energy released from cutting hard metals.
  • Wireless communication to connect with Greenlee Link App to track tool performance.
  • Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback.
  • State of the art 18V lithium ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times.
  • Retraction Stop allows the operator to stop the ram retraction at any point simply by tapping the trigger, and then starting the next cutting cycle from that point, saving time and energy.
  • Two-stage hydraulic system provides fast advance and power speeds, saving time.
  • One trigger controls all tool functions.
  • Cutting head rotates 350°.
  • Tools automatically retract when the cutting cycle is complete.
  • Over mold tacky grip areas make gripping the tool easier and more comfortable.
  • LED work light illuminates dark work areas
  • Greenlee battery-powered cutting tools use bio-degradable oil.
  • Smart Chargers control the charging current, charging voltage and battery temperature to maximize battery life.

Specifications

Sub-brand Gator
Type Guillotine-style cable cutter
Application Aluminum conductor steel-reinforced (ACSR), guy wire, steel
Cutting edge Hard metal, steel
Cutting range Aluminum-steel cables: 1 590 kcmil (MCM)
Cutting range Standard guy wire cable: 16 mm (5/8 in) diameter
Cutting range EHS guy wire cable: 89 mm (1/2 in) diameter
Cutting range Mild steel bolt: 19 mm (3/4 in) diameter
Jaw size 45 mm (1,77 in)
Overall length 463 mm (18,25 in)
Handle type Linear with overmoulded rubber grip
Finish Black
* Greenlee® may make improvements and/or changes in product specifications at any time, at its sole discretion, without notice or obligation, and further reserves the right to change or discontinue models.
Supply voltage 230 V (not compatible in Quebec)
Weight 16.68 lbs
Dimensions 23 × 12.01 × 8.02 in
Sub Brand

Gator
Type

Guillotine Style Cutter
Application

ACSR, Guy Strand, Steel
Cutting Edge

Hard Metal, Steel
Cutting Range

Soft Steel Bolt: 3/4 IN Diameter
Jaw Size

1.77 IN (45mm)
Overall Length

18.25 IN (463mm)
Handle Type

In-line style with over molded rubber grip
Finish

Black
Catalog number ESG45LX22 Categories , , , ,
