Quick-release die head for 1/4″ – 1″ Left/Right Bolts 531 (97045)534.77$
Quick-release die head for 1/4″ – 1″ Left/Right Bolts 531 (97045)
534.77$
Add the desired quantity to the selected products.
531 1/4″-1″Bolt Die Head Quick-Open R.H./L.H.
The Model 535A maintains the ruggedness of the industry workhorse while adding features that make the threading operation more productive. A large chip tray and oil reservoir make the 535A ideal for longer uninterrupted threading. The 535 features a high clearance carriage that makes the threading operation easier and a generous top cover area that is ideal for keeping tools and work related materials handy. The 535A is designed around maximum uptime with the upgrades that matter most to the pipe working professional. Users also benefit from the part commonality between the 535, the 535A Automatic and other RIDGID® equipment.
Ordering Information
| CATALOG NUMBER | MODEL NO. | DESCRIPTION | DIE HEAD | RPM | VOLTAGE (V) | FREQUENCY (HZ) | PHASE | MOTOR TYPE | AMP DRAW (A) | POWER | WEIGHT (LB.) | WEIGHT (KG) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 61142 | 1215 | 1215 120V DOMESTIC | 811A | 44 | 115 | 60 | 1 | Universal | 13 | – | 80 | 36.00 |
| 61187 | 1203 | 1203 Tripod Stand | 15 | – | ||||||||
| 97045 | 531 | 531 1/4"-1"Bolt Die Head Quick-Open R.H./L.H. | 7 1/2 | 3.40 | ||||||||
| 84537 | 816 | 816 1/8” – 3/4” NPT Die Head, Semi-Automatic, RH | 13 | 5.90 | ||||||||
| 84532 | 817 | 817 1” – 2” NPT Die Head, Semi-Automatic, RH | 13 | 5.90 |
| Model no. | 531 |
|---|---|
| Weight | 7.87 lbs |
| Dimensions | 11.2 × 9.3 × 3.9 in |
| MODEL NO. | 531 |
| HOW OPENED | Q.O |
| THREAD DIRECTION | RH/LH |
| OIL THRU HEAD | Yes |
| DIES USED | 500B |
| BOLT CAPACITY (IN.) | 1/4 – 1 |
| BOLT CAPACITY (MM) | 3 – 25 |
| WEIGHT (LB.) | 7 1/2 |
| WEIGHT (KG) | 3.4 |
